£777.99
RCM/Omega 2618A flat-top forged piston set for EJ20 engine blocks. Choose 92.00 mm standard, 92.25 mm oversize or 92.50 mm oversize; each option is a four-piston set with rings, pins and circlips.
Typical lead time: 1–3 working days, subject to supplier stock.
Description
RCM/Omega flat-top forged pistons for EJ20
This RCM/Omega piston family is supplied in three verified bore sizes for Subaru EJ20 engine blocks. Choose the finished bore required by the engine builder; each selectable option has its own manufacturer SKU.
These are flat-top, non-stroker pistons. RCM does not publish one fixed compression ratio for the family because the achieved compression depends on the cylinder heads, head-gasket thickness, connecting-rod length and crankshaft specification. This listing therefore identifies the crown form and bore accurately without inventing a compression figure or interchangeability with RCM’s dedicated stroker piston families.
Selectable bore sizes
- 92.00 mm standard bore — RCM2241.
- 92.25 mm oversize — RCM2242.
- 92.50 mm oversize — RCM2243.
Supplied set
- Four RCM/Omega forged pistons.
- Matching piston-ring set.
- Gudgeon pins and circlips.
Construction
RCM specifies 2618A aerospace-alloy forgings, CNC machined and quality checked at a controlled 20.5°C. The piston skirts use an elliptical cross-section and barrelled length profile for operation at working temperature. RCM/Omega pistons are individually weighed and batched within 0.5 grams.
Fitment and ordering
RCM confirms this family for EJ20 engine blocks. Before ordering, have the engine builder confirm the exact block, finished bore, piston-to-bore clearance, cylinder-head and head-gasket combination, connecting-rod length and crankshaft specification. Oversize pistons require the corresponding finished bore; do not select by vehicle model alone.
Additional information
| Weight | 3 kg |
|---|---|
| Dimensions | 30 × 25 × 15 cm |
| Piston Size | 92.25mm Oversize, 92.5mm Oversize, 92mm Standard size |
| Engine / crown family | EJ20 flat-top piston family; separate from dedicated stroker piston families |
| Set contents | Four pistons, piston rings, gudgeon pins and circlips |
