£2,282.00
Non Stock Item – Ordered In
Typical lead time: 1–3 working days, subject to supplier stock.
Typical lead time: 1–3 working days, subject to supplier stock.
SKU: 871389-5004S
Category: Universal Fit Turbos
Tags: G25-550 Turbo Assembly, Garrett, Impreza Performance Parts, Impreza specialist, sti, subaru performance parts, Subaru Specialist, Subaru west midlands, Turbo Assembly 300-550HP
Description
Garrett G25-550 Turbo Assembly 300-550HP
Horsepower: 300 – 550HP
Displacement: 1.4 – 3.0L
Garrett® G Series Compressor Aerodynamics for maximum HP. Fully machined Speed Sensor and pressure ports. New Turbine Wheel Aero constructed of MAR-M alloy rated 1055ºC. Stainless Steel wastegated and non wastegated turbine housing option capable of 1050°C. Oil restrictor and water fittings included.
- Compressor side: Trim 65 A/R 0.70
- Compressor Air Inlet: Hose 3″ (76.2mm)
- Compressor Air Outlet: Hose 2″ (50.8mm)
- Turbine side: Trim 84 A/R 0.72
- Turbine Inlet: V-Band 3″ (76.2mm)
- Turbine Outlet: V-Band 3.55″ (90.17mm)
- Non wategated
Forged fully-machined compressor wheel and new aerodynamics increase maximum horsepower output and boost response. The CFD (computational fluid dynamics) engineered compressor wheel increases air flow up to 15% for 60mm and 30% for 67mm with 79-80% efficiency. (Compared to GTX GenII)
Rear turbo housing not included
871389-5004S
